1.Up to 460W front power and 21.0% module efficiency with half-cut and
MBB (Multi Busbar) technology bringing more BOS savings
2. 2% first year degradation,0.55% Annual Power Attenuation
Brand :
TrinaMax. Efficiency :
21%Number of Cells :
144cellsDimension :
2102×1040×35mmWeight :
24kgJunction Box :
IP68 Rated, 3 DiodeCable :
4.0mm2, Portrait: 300mm / Landscape: 1300mmWind/Snow Load: :
2400Pa/5400PaConnector :
MC4 CompatiblePower Range :
450-460wWarranty :
25 YearsPayment :
T/T,Credit Card, Paypal, Western UnionCertification :
IEC/CE/TUV/CSA/CEC/UL1.High power
Up to 460W front power and 21.0% module efficiency with half-cut and
MBB (Multi Busbar) technology bringing more BOS savings
• Lower resistance of half-cut and good reflection effect of MBB ensure high
power
2.High reliability
Ensured PID resistance through cell process and module material control
• Resistant to salt, acid and ammonia
• Mechanical performance: Up to 5400 Pa positive load and 2400 Pa negative
load
3.High energy generation
• Excellent IAM and low light performance validated by 3rd party with cell
process and module material optimization
• Better anti-shading performance and lower operating temperature
Electrical Specification
Module Type | Tall Max 450W | Tall Max 455W | Tall Max 460W |
Maximum power (Pmax/W) | 450 | 455 | 460 |
Open-circuit voltage (Voc/V) | 49.6 | 49.8 | 50.0 |
Short circuit current (Isc/A) | 11.53 | 11.61 | 11.68 |
Peak power voltage (Vmp/V) | 41.0 | 41.2 | 41.3 |
Peak power current (Imp/A) | 10.98 |
11.06 |
11.13 |
FAQ:
What watts of this panel?
Mono 450w 460W solar panel
What dimension of this panel?
2102 ×1040× 35 mm
How Many pcs quantity of one container? How much is the loading quantity and shipping method?
31pcs/pallet. 682pcs/40HQ;Shipping normally by sea because of the heavy weight, but we can provide DDP(door-to-door) service if needed.
How long is the Delivery time?
Normally production will takes around 10 workings days, depends on the order quantity.
