N type Topcon Solar Module 700W Solar PV Panel With TUV CE

N type Topcon Solar Module 700W Solar PV Panel With TUV CE

UNI 6 Series 132 Half-Cells Mono Solar Module 680watt 685W 690W 695Wp 700Watt

Bloomberg Tier 1 HJT Technology MBB Photovoltaic Solar Panel Module Based on 210mm Solar Cell

Brand :
United Energy Or OEM Service
Max. Efficiency :
22.54%
Number of Cells :
132Cells (6x22)
Dimension :
2384*1303*35mm
Weight :
33.6kg
Junction Box :
IP68 Rated, 3 Diode
Cable :
4.0mm2, Portrait: 300mm / Landscape: 1300mm
Wind/Snow Load: :
2400Pa/5400Pa
Connector :
MC4 Compatible
Power Range :
675-700w
Warranty :
25 Years
Payment :
T/T,Credit Card, Paypal, Western Union
Certification :
IEC/CE/TUV/CSA/CEC/UL

Inquiry now

product introduction

United Energy founded in 2009, National high-tech enterprise,focus on solar panel R&D obtained more than 100 patents.

Quality is the Company Culture of UNITED ENERGY!

1. The hot spot temperature of the half-chip module assembly is lower than the temperature of the same-type full-piece module assembly by about 25 ° C, which can effectively reduce the hot spot effect of the component.

2. Half-cut module components meet the 1500V system voltage design requirements, which can reduce the system-side cost by about 10%

3. Effectively reduce the loss of power generation caused by occlusion when there is shadow occlusion and ash accumulation or snow accumulation.

4. Reduce the first year and the average photoinduced attenuation

5. 100% PID Free.

Electrical Specification

Model Number	UE675M-66H	UE680M-66H	UE685M-66H	UE690M-66H	UE695M-66H	UE700M-66H
Maximum Power (Pmax/W)	675	680	685	690	695	700
Open Circuit Voltage (Voc/V)	46.3	46.5	46.7	46.9	47.1	47.3
Short Circuit Current (Isc/A)	18.68	18.73	18.78	18.83	18.88	18.93
Voltage at Maximum Power (Vmp/V)	38.4	38.6	38.8	39	39.2	39.4
Current at Maximum Power (Imp/A)	17.58	17.62	17.66	17.7	17.73	17.77
Efficiency (%)	21.73	21.9	22.06	22.22	22.38	22.54

Key Features of United Energy Solar Panel

1.50W increase compared with Perc of the same version

2.Passed the standard test of 3 times IEC for greater reliability

3.HJT new production technology

4. Superior Warranty-12 years products warranty 25 years linear power output warranty

5. Full set of safety certification and regulation, meet certificate requirements in most of the countries.

Why Choose Us

United Energy focusing on R&D and manufacture of solar energy systems, meet EU and U.S. regulations, dedicated to making safer and more efficient Solar Energy Solutions.

50%+ of the sales engineers are having 10+ years experience you can always trust UE team since they have developed 5,000+ overseas distributors and Installers from ground up.

FAQ：

What watts of this panel?

Mono 660w 670w 680w 690w 700w solar panel.

What dimension of this panel?

2384 x 1303 x 35mm

How much is the loading quantity and shipping method?

31pcs/pallet 558pcs/40HQ; Shipping normally by sea because of the heavy weight, but we can provide DDP(door-to-door) service if needed.

How long is the Delivery time?

Normally production will takes around 10 workings days, depends on the order quantity.
