Factory Audit;
Goods Inspection;
Third Party Test.
1.Multi-busbar Design
Our nine-busbar design further improves current collection capabilities.
2.Half-Cell Modules
The power of half-cell module increases, and the hot spot temperature reduces because of lower working current
Brand :
LONGIMax. Efficiency :
21.2%Number of Cells :
144cellsDimension :
2094×1038×35mmWeight :
24.3kgJunction Box :
IP68 Rated, 3 DiodeCable :
4.0mm2, Portrait: 300mm / Landscape: 1300mmWind/Snow Load: :
2400Pa/5400PaConnector :
MC4 CompatiblePower Range :
450-460wWarranty :
25 YearsPayment :
T/T,Credit Card, Paypal, Western UnionCertification :
IEC/CE/TUV/CSA/CEC/UL1.Electrically Compatible
Operating current lower than 11A;
Good for distributed generation applications; Matches with various inverters and optimizers; Avoids wiring loss.
2.Multiple Size Configurations
Standardized width, choice of three different lengths, full utilization of limited roof area, realizing the maximum installed capacity
3.Gallium-doped Technology
Gallium-doped technology overcomes LID degradation and guarantees the long-term power generation of the module.
4.Installation on Any Roof
Flexible installation, including pitched roof, flat and angular roof and flat roof with herringbone detail
5.Power Warranty
1st year degradation ≤2%, linear degradation ≤0.55%/year
Electrical Specification
Module Type | LR4-72HPH-450M | LR4-72HPH-455M | LR4-72HPH-460M |
Maximum power (Pmax/W) | 450 | 455 | 460 |
Open-circuit voltage (Voc/V) | 49.3 | 49.5 | 49.7 |
Short circuit current (Isc/A) | 11.6 | 11.66 | 11.73 |
Peak power voltage (Vmp/V) | 41.5 | 41.7 | 41.9 |
Peak power current (Imp/A) | 10.85 |
10.92 |
10.98 |
FAQ:
What watts of this panel?
Mono 450w 455W 460W
What dimension of this panel?
2094*1038*35mm
How Many pcs quantity of one container? How much is the loading quantity and shipping method?
30pcs/pallet. 150pcs/20ft.660pcs/40HQ; Shipping normally by sea because of the heavy weight, but we can provide DDP(door-to-door) service if needed.
How long is the Delivery time?
Normally production will takes around 10 workings days, depends on the order quantity.
